PCB Design at the Connected Humber Hardware Group Meetup

Thanks to Robin for the picture

Thanks to Robin for the picture

We had another great session at the Connected Humber Hardware Group tonight. Paul was telling us how to design our own printed circuit boards and get them made up. This is now so cheap that every electronics hobbyist should be getting their own custom boards made up. It turns out that it is all a matter of workflow, in that the sequence in which you put the design together is the important part. Unfortunately I was helping out with a recalcitrant LCD panel during this bit, so I’ll have to ask the other members to help me along when I start making my own circuits.

I want to make at least four, one for the fully featured Air Quality sensor, one for the “Mini MQTT” sensor, another for the Hull Pixelbot dual brain version and a final one as a badge which I think will look cool.

We’ll be continuing our exploration of PCB design at later meetups. They are free to attend, great fun, and take place on the first and third Thursday of each month at c4di in Hull. You can just turn up on the day (as a bunch of people did tonight) but you can also sign up for notification of upcoming events here.
